32CBM 12 - 16 Tons Refrigerated Truck Cargo Body 6.3m Length Insulated CKD Panels

32CBM 12 - 16 Tons Refrigerated Truck Cargo Body 6.3m Length Insulated CKD Panels

  • 32CBM 12 - 16 Tons Refrigerated Truck Cargo Body 6.3m Length Insulated CKD Panels
  • 32CBM 12 - 16 Tons Refrigerated Truck Cargo Body 6.3m Length Insulated CKD Panels
  • 32CBM 12 - 16 Tons Refrigerated Truck Cargo Body 6.3m Length Insulated CKD Panels
  • 32CBM 12 - 16 Tons Refrigerated Truck Cargo Body 6.3m Length Insulated CKD Panels
32CBM 12 - 16 Tons Refrigerated Truck Cargo Body 6.3m Length Insulated CKD Panels
جزئیات محصول:
Place of Origin: China
نام تجاری: SINOTRUK
گواهی: ISO/3C/BV/IFA/SGS
Model Number: 6.3m Length cargo body
پرداخت:
Minimum Order Quantity: 1 Unit
قیمت: negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2,000units per month
مخاطب
توضیحات محصول جزئیات
Min. حداقل Temperature درجه حرارت: -18 درجه سانتیگراد مدل: بدنه بار به طول 6.3 متر
نام محصول: پانل های CKD کامیون های یخچال دار ابعاد بیرونی: 6300*2500*2500 میلی متر
ابعاد داخلی: 6135*2335*2340mm جلد: 32.45 CBM
ظرفیت بارگیری: 16 - 20 تن کف آلومینیومی: 14.4 ㎡
در کناری: ONE فن آوری: آلمانی
ضخامت: 105 میلی متر
برجسته:

کامیون جعبه یخچال دار

,

کامیون مواد غذایی یخچال دار

,

کامیون یخچال دار 16 تنی

Insulated CKD Panels for making refrigerated truck cargo body 32CBM 12-16tons



Description:



Insulated CKD Panels for making refrigerated truck cargo body 32CBM 12-16tons

The RFID tag has the following main advantages: RFID tag data storage, reusable, low cost, convenient operation, read and write 30-100 meters in distance; the RFID tag, can monitor the temperature of different units in different packaging of a container; the RFID tag provides ID code, and can continuously record the temperature the data, accurate time records, easy responsibility and bound, information can quickly grasp the temperature of the back, the most important fresh degree in the management of transportation, and promote the circulation of fresh degree of management improvement; RFID can be extended by the enterprise or the cold chain alliance testing center platform covering the whole process of the cold chain; in the area of automatic notification and automatic unloading door registration; effective management of truck traffic, real-time monitoring and state; shorten the waiting time, improve operational efficiency; optimization of truck traffic Management, so as to speed up the logistics process of JIS and JIT; reduce the loss of products, improve the safety of product transportation, and improve enterprise income.



The management system of refrigerated transport vehicle positioning will assist in China's logistics

industry monitoring technology breakthrough bottleneck at this stage the establishment of cold chain logistics management an effective method provides a successful example effective and beneficial.



Specification:



Insulated CKD Panels for making refrigerated truck cargo body 32CBM 12-16tons

Outside Dimension

6300*2500*2500mm

Inside Dimension

6135*2335*2340mm

Volume

32.00CBM

ANTI-PRESSURE

>180MPa

Van Heat Transfer Coefficient

≤0.3W/M2﹒K

ANTI-CURVE

>220MPa

CUT STRENGTH

>24.6MPa

Side door

1

Aluminum floor

14.4 ㎡

Main Components

body assembly

Material

Freon-free polyurethane, and GRP material

Floor or roog



105mm




Applications:





Refrigerated Truck can widespread use in transportation of all kind of frozen food, vaccinum, vegetables and fruit.



Competitive Advantage:



1)with all kinds of truck model, which can fulfill your requirement
2) the key parts adopt the world's top technology products
3) based on strong technical support and top level technology make the trucks with high

quality and more reliable
4) competitive price, cost-effective

5) quick and efficient spare parts supply bring you more convenient

6) fast delivery time, we can arange production according to your needs exactly and quickly

7) professional import and export dealing precedure, make customs clearance more high efficiency

8) Our company's production of circular easy brand refrigerator car introduced Italy,

Germany, the United States overall polyester foam technology, and high strength fiber

plastic and other material  manufacturing technology and equipment

9) so that our company refrigeration, heat preservation technology level basic reached

world advanced  water level.
10) Refrigeration, heat preservation car body with light, high strength, good heat

insulation performance,  high temperature stability, no pollution, oxidation, easy

maintenance, but also has low noise, low energy consumption, low failure rate, food

preservation effect is good and so on a series of advantages
11) A lot of technical indicators and the world's advanced level is close to the fully

closed polyurethane  plate bonded glass steel structure, this product is light weight,

low heat leakage.
