Place of Origin: | China |
نام تجاری: | SINOTRUK |
گواهی: | ISO/3C/BV/IFA/SGS |
Model Number: | 3 Axles 50000 Liters Oil carrying Trailer |
Minimum Order Quantity: | 1 Unit |
---|---|
قیمت: | negotiable |
Packaging Details: | Nude or Waxing in Roro or bulk ship, or by 40GP, 40HQ,40FR and so on |
Delivery Time: | 20 working days after received your advance payment |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 4,000units per month |
Product Name: | Semi Trailer Oil Tank Truck | Model: | 3 Axles 50000Liters |
---|---|---|---|
Fifth Wheel: | #50, #90 | Loading capacity: | 50-80tons |
Tank Capacity: | 45-60CBM | Thickness of Tank body: | 4mm 5mm 6mm Optional |
Axles: | 3X13 tons,3X16 tons | Material: | Carbon steel or Mn steel |
برجسته کردن: | Semi Trailer Dump Truck,hydraulic flatbed trailer,hydraulic flatbed trailer |
HOWO A7 Large Capacity Tri - Axle Diesel Tanker Semi Trailer Truck 50 - 80Tons
Description:
HOWO A7 Large Capacity Tri - Axle Diesel Tanker Semi Trailer Truck 50 - 80Tons
Semi Trailer Tank Truck is divided into two parts, oil tank part and a support body
skeleton or driving part is traction head connecting Trailer tanker, compared with
ordinary single type tank truck, semi-trailer tank truck can effectively improve the
transportation efficiency. In the same tonnage and reduce the transportation cost,
saving fuel. The rear of Semi trailer tank is approximately the same,which have 2 Axles
and 3 Axles, according to the need to choose the traction head.
According to customer's special requirements for the use of centrifugal pumps, gear
pumps, stainless steel pumps, with large flow, fast suction speed and so on.
Tanker measurement can choose single count, flow meter double counting, assembly tax
controlled computer refueling machine, installed 10 to 15 meters automatic telescopic
return reel, equipped with a gas gun. Edible oil can be used edible oil computer meter
to measure.
Tank body using 4mm or 6mm quality carbon steel according to the national standard, the
shape of oval or square round tank, can be installed 1-4 kinds of oil. Also can produce
heating insulation series tank.
The tank design using multi channel swash plate. Using high pressure gas leakage
detection, the tank has characteristics of high strength, stable center of gravity, high
vehicle safety and stable and so on.
Specification:
HOWO A7 Large Capacity Tri - Axle Diesel Tanker Semi Trailer Truck 50 - 80Tons
|
|
Model | 3 Axles 50000Liters |
Axle |
FUWA brand, 13ton, 3 Sets |
Main beam |
Beam height: 500mm Upper plate: 10mm Double Middle plate: 6 mm Down plate: 12mm |
Tank Body Thickness |
4mm, 5mm, 6mm optional |
Material |
Carbon steel or Mn steel |
Gross vehicle weight |
65000kgs |
King pin |
#90 |
Support leg |
JOST Standard 28T |
Suspension |
Normal suspension |
Thickness leaf spring |
10/10/10 |
Tire/Rim |
1200R20, 13pcs, 8.5, 12 pcs |
Brake Chamber |
Standard 6 pcs |
Spare wheel carrier |
2 pcs |
Tool box |
1 pcs |
Electrical System |
Chinese standard 24C lighting system |
Side Maker Lamp |
LED lamp |
Painting |
Polyurethane Paint |
Overall dimension |
14100×2500×3780(mm) |
Color | White, red, green, golden and so on. |
Applications:
It’s suitable for storage and carrying all kinds of Oils .
Competitive Advantage:
1) it has higher safety and running efficiency.
2) Optimized structure design, let it have lower self weight, but more stonger
3) excellent appearance of cabin, safety, reliable
4) low fuel consumption
5) the key parts adopt the world's top technology products
6) based on strong technical support and top level technology make the trucks with high
quality and more reliable
7) competitive price, cost-effective
8) quick and efficient spare parts supply bring you more convenient
9) fast delivery time, we can arrange production according to your needs exactly and Quickly
10) professional import and export dealing procedure, make customs clearance more high efficiency
