SINOTRUK HOWO Tractor Truck LHD 6X4 10 Wheels Euro2 336 HP ZZ4257S3241W

SINOTRUK HOWO Tractor Truck LHD 6X4 10 Wheels Euro2 336 HP ZZ4257S3241W

  • SINOTRUK HOWO Tractor Truck LHD 6X4 10 Wheels Euro2 336 HP ZZ4257S3241W
  • SINOTRUK HOWO Tractor Truck LHD 6X4 10 Wheels Euro2 336 HP ZZ4257S3241W
  • SINOTRUK HOWO Tractor Truck LHD 6X4 10 Wheels Euro2 336 HP ZZ4257S3241W
  • SINOTRUK HOWO Tractor Truck LHD 6X4 10 Wheels Euro2 336 HP ZZ4257S3241W
SINOTRUK HOWO Tractor Truck LHD 6X4 10 Wheels Euro2 336 HP ZZ4257S3241W
جزئیات محصول:
Place of Origin: China
نام تجاری: SINOTRUK HOWO
گواهی: ISO/3C/BV/IFA/SGS
Model Number: ZZ4257S3241W
پرداخت:
Minimum Order Quantity: 1 Unit
قیمت: USD36500-USD37000/UNIT)negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 20 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 4,000units per month
مخاطب
توضیحات محصول جزئیات
Product Name: Tractor Truck Model: ZZ4257S3241W
Drive type: LHD 6X4 Emission Standard: Euro 2
Engine: WD615.69, 336HP Fifth Wheel: #50, #90
Traction capacity: 60-70tons Cabin: HW76
برجسته:

tractor trailer truck,howo tractor truck

,

howo tractor truck

SINOTRUK HOWO Tractor Truck LHD 6X4 10 Wheels Euro2 336HP ZZ4257S3241W



Description:



SINOTRUK HOWO Tractor Truck LHD 6X4 10 Wheels Euro2 336HP ZZ4257S3241W

This model is the proven product of SINITRUK, which features reliable structure, great loading capacity, excellent power from 266-420HP, reliable performance. This model can meet the requirements of different road conditions. This model can satisfy your need of long distance highway transportation.

Highway transport is divided into two version, to match the different condition of transportation needs.



The first version of the highway transport is equipped with aluminum shell transmission MCY13 (Q) single reduction drive axle and other lightweight configuration, mainly used for standard load level (It means that the total weight of tractor train within 55 tons, the total weight of bike within 41 tons); When the first version of the tractor adopts the plate spring suspension, disc brake MCY13 (Q) single stage drive axle can be opted.


The fifth version of the highway transport is equipped with iron reinforced frame, Iron shell transmission and two-stage reduction drive axle which can loaded16 ton, single-stage reduction drive axle, which can loaded 16 ton is optional, mainly used for comprehensive road conditions and overloading of the transport conditions.







Specification:



SINOTRUK HOWO Tractor Truck RHD 6X4 10 Wheels Euro2 371HP ZZ4257S3241W

Model ZZ4257S3241W
Drive Type 6×4
Engine

WD615.69 , 336HP( Euro II)

6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

Displacement : 11.596L

Cabin HW76(with single sleeper, air-conditioner and new-style seat)
Transmission HW19710(10 forwards & 2 reverses)
Front Axle 1×HF9 ( 9 Tons)
Driving Axle HC16, 16Tons
Steering ZF8098 hydraulic steering with power assistance.
Clutch

Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with

 air assistance

Rim/ Tire

12R22.5 tubeless tyre

11.00R20,12.00R20,12.00R24 Radial tire
Wheel base 3200+1350(mm)
Overall dimension

6800×2496×2958(mm)

Fifth Wheel

#50, #90

The curb weight 9180(Kg)
Gross weight 25000 kg
Max. speed 102km/h
Color White, red, green, golden and so on.




Applications:



It’s suitable for towing all kinds semi trailer which is used in Logistics business, construction site and

Mining area .



Competitive Advantage:



1)low fuel consumption

2)strong enough engine

3)with all kinds of truck model, which can fulfill your requirement

4)the key parts adopt the world's top technology products

5)based on strong technical support and top level technology make the trucks with high quality and more reliable

6)it has higher safety and running efficiency.

7)excellent appearance of cabin, safety, reliable

8)competitive price, cost-effective

9)quick and efficient spare parts supply bring you more convenient

10)fast delivery time, we can arrange production according to your needs exactly and Quickly

11)professional import and export dealing procedure, make customs clearance more high efficiency
